This flexible, lightweight, and extreme terrain master is brand new for 2020, and now it proudly has TPI (Transmission Port Injection) letters next to its name. It merely means that there is no need to re-inject or mix fuel, making this easily chopped thoroughbred easier to ride and work. The new KTM 2020 150 XC-W TPI Dirt Bike has been recognized for its outstanding agility. It benefits from a new frame, improved bending characteristics, and many other recent changes that help elevate the rider and the machine incredibly new level.
KTM 2020 150 XC-W TPI Dirt Bike – Features
Top Features
This KTM 2020 150 XC-W TPI Dirt Bike comes with a new 143.99 ccs 2-stroke motor fitted with a licensed TPI fuel infusion framework for great powering at any height, no premixing, and decreased fuel utilization while as yet satisfying the standard of a KTM 2-stroke. A new chamber with two injectors put in the back-exchange ports for excellent downstream atomization of fuel. It has new fumes port planning with CNC machined edge for improved base end force, and execution over the rpm go. KTM also added a new silencer with aluminum sections supplanting the plastic mounting framework. Super lightweight Galfer Wave rotors, CNC machined centers, top of the line Giant edges, and Dunlop GEOMAX AT81 tires.
EMS is highlighting another ECU controlling start timing and fuel-dependent on data from sensors perusing admission gaseous tension choke position, water temperature, and surrounding air pressure from another extra sensor that improves height remuneration. A discretionary guide select switch permits the rider to choose a substitute guide, giving a sportier power conveyance. At the same time, the standard principle is set for smoother and more manageable rough terrain attributes. New more grounded and very light Lithium-Ion battery offers a better beginning and diminished weight for improved taking care.
KTM designed a new 39 mm choke body by Dell ‘Orto with revamped inactive and cold beginning frameworks for better flexibility of fixed speed and cold beginning advancement. Electronic oil siphon takes care of oil from the 700-cc oil tank to the admission. It guarantees an ideal fuel-oil blend under any condition while diminishing smoking by half and giving up to 5 tanks of fuel. It just has a new design for a READY TO RACE appearance. A modern edge created as a team with KTM industrial facility racers highlight improved firmness for extraordinary dealing with and straight-line strength.
This Dirt Bike includes a new aluminum head that remains for improved motor obsession. A 40 mm longer subframe gives improved back bumper soundness. The bodywork is planned with overall ergonomics for the expanded opportunity of development and improved taking care of and comfortable. A newly formed seat offers better ergonomics and solace for long rides in requesting territory. New airbox and admission boot give the most extreme assurance of the air channel against ruining and better wind stream for ideal execution. It has new fumes pipe with a streamlined shape for improved base end power.
KTM 2020 150 XC-W TPI Dirt Bike has reworked wiring saddle and bundling for a minimized electrical framework. Newly planned radiators with an improved cooling framework for more professional cooling and a 12 mm lower mounting position for enhanced taking care. Updated WP XPLOR forks with a split-work configuration include another adjusted mid-valve cylinder for more reliable damping. It also has new fork tops with new agents and new settings to keep the front end higher for better rider input and expanded bottoming opposition. “No Dirt” move switch keeps dirt from fouling the switch joint to guarantee appropriate moving in any condition.
Updated WP XPLOR back stun with PDS innovation includes another subsequent cylinder and modified state of the fixing cup for improved bottoming obstruction while new settings offer improved solace. 6-speed PANKL complete proportion transmission is appropriate for rough terrain obligation. The pressure-driven Brembo grip framework offers light activity and a profoundly controllable adjustment of the grasp. High-tech Brembo brakes have consistently been standard gear on KTM rough terrain bikes and are joined with lightweight Wave plates for most extreme execution. KTM’s “No Dirt” footpeg configuration keeps the pegs rotate from getting stopped up, guaranteeing the footpeg is consistently in the right position.
Motor and Exhaust
KTM sets the benchmark in innovation with its tremendous scope of race-winning rough terrain rivalry 2-stroke models. Two years later, the presentation of the world’s initial two-stroke electronically controlled fuel infusion rough terrain models. The example of overcoming difficulty proceeds with totally revised, new age rugged terrain rivalry motors, all fitted with the progressive TPI framework. It presently likewise incorporates the KTM 150 XC-W TPI, further demonstrating KTM’s continuous duty to 2-stroke progression. The advantages are clear: other than colossal enhancements in eco-friendliness and fumes discharges, the framework additionally expels the requirement for pre-blending fuel and re-streaming. It implies that with less exertion, the motor consistently runs quickly and freshly.
Suspension and Ergonomics
With regards to 2-stroke weaponry, holding weight down is critical. An all-new KTM 2020 150 XC-W TPI Dirt Bike is one of the lightest, slimmest, and most elegant rough terrain machines in its group. Intended for complete concordance among rider and bike, KTM has abused the information from many years of race accomplishment to make ideal ergonomics on the KTM 150 XC-W TPI. Greatest rider solace and development in all conditions is ensured. Also, the bike includes another tail light structure that fits impeccably to the new state of the back bumper and the number plate transporter.
Bodywork and Electronics
With contribution from KTM’s processing plant riders, just as KTM R&D and Kiska Design, the new bodywork of the KTM 150 XC-W TPI pushes the limits of movement much further. The outcome is a shape over the whole range, that accomplishes total amicability among rider and bike. The principal objective was to give the ideal contact focuses that permit a rider’s most extreme opportunity of development. The front and back bumpers include an innovative I-pillar configuration, ensuring the most extreme security with the least conceivable weight. Another tail light structure fits impeccably to the new state of the back bumper and the number plate transporter.
The new in-shape illustrations affirm the only goals of this bike, just as KTM’s ongoing journey for the race-winning movement. KTM XC-W TPI models highlight the most current motor administration arrangement of any 2-stroke rough terrain motorcycle. By perusing different sensor information inputs, for example, consumption and surrounding pneumatic force, choke valve position, and water temperature, the control unit enhances start timing and the measure of fuel to infuse at all elevations and conditions.
KTM 2020 150 XC-W TPI Dirt Bike – Technical Specification
Engine
Type | Single Cylinder, 2-Stroke |
Displacement | 143.99 cc |
Bore/Stroke | 58/54.5 mm |
Starter | Electric, Lithium-Ion 12 V 2 Ah / Kickstarter |
Transmission
Gearbox | 6 Gears, Wide Ratio |
Fuel System | TPI, Dell’Orto 39 mm Throttle Body |
Lubrication | Electronically Regulated Oil Pump |
Primary Ratio | 23:73 |
Final Drive | 13:50 |
Cooling | Liquid Cooling |
Clutch | Wet Multi-Disc Clutch, Brembo Hydraulics |
Ignition | Continental EMS |
Chassis
Frame | Central Double-Cradle Type 25CrMo4 Steel |
Subframe | Aluminum |
Handlebar | NEKEN, Aluminum Ø 28/22 mm |
Front Suspension | WP XPLOR USD Ø 48 mm |
Rear Suspension | WP XPLOR Shock with PDS |
Suspension Travel Front / Rear | 300 mm / 11.8 inches; 310 mm / 12.2 inches |
Front/Rear Brakes | Disc Brake 260mm, 220mm |
Front/Rear Rims | 1.60 x 21-inch / 2.15 x 18-inch Giant |
Front/Rear Tires | 90/90-21-inch / 110/100-18-inch Dunlop GEOMAX AT81 |
Dimension
Chain | 5/8 x 1/4 inches |
Silencer | Aluminum |
Steering Head Angle | 26.5-degree |
Triple Clamp Offset | 22 mm |
Wheelbase | 1,471 mm ± 10 mm / 57.9 ± 0.4 inches |
Ground Clearance | 370 mm / 14.6 inches |
Seat Height | 960 mm / 37.8 inches |
Tank Capacity | 9 l / 2.4 gallons |
Weight (without fuel) | 96.8 kg / 213.4 lbs |
Conclusion
Just like the previous 150XC-W, the TPI version quickly became the favorite choice for the riders to ride on any occasion. The engine of the KTM 2020 150 XC-W TPI Dirt Bike has undergone drastic changes. KTM has redesigned certain parts with greater lateral, longitudinal, and torsional stiffness to improve rider comfort and overall stability.
