An ATV isn’t what the KingQuad 750AXi Power Steering SE Plus is — it’s an ATV made by KingQuad. The world’s best sports-utility quad, designed by Suzuki, the inventor of the four-wheel ATV, boasts stunning style, unmatched capability, and unmatched reliability.
Now, you can be a part of the enduring history of KingQuad, whose legacy is still fascinating and relevant today. The 2023 KingQuad 750AXi Power Steering SE Plus Utility ATV uses unique KingQuad features to help navigate rugged terrain.
2023 KingQuad 750AXi Power Steering SE Plus Utility ATV – Features and Specs
Key Features
Aggressive bodywork of 2023 KingQuad 750AXi Power Steering SE Plus Utility ATV in new cast carbon pattern with cast wheels with machined rim and spoke edges, or blacked-out cast aluminum wheels in metallic matte Rocky Gray. Sharp, bold looks, an easy riding position, and electronic power steering that require little effort.
Also Read:Â Suzuki 2023 KingQuad 750AXi Power Steering SE Camo Utility ATV Review
EFI-fed, torque-rich engine with an efficient QuadMatic transmission and engine brakes. Headlights fenders and handlebars, an LED tail light, and a full LCD instrument panel. Your KingQuad can be configured with a sturdy, detachable cargo rack cover for any assignment.
Engine Features
The potent 722cc DOHC single-cylinder, liquid-cooled, four-stroke engine is tuned to produce excellent peak power and strong low-to-mid-range torque.
To help prolong engine life of new 2023 KingQuad 750AXi Power Steering SE Plus Utility ATV, the engine’s high-capacity oil pump supplies the piston oil jet system with a powerful cooling oil flow.
The engine and seat height are reduced, resulting in the cylinder and head being moved forward for a lower center.
Dust and water are avoided using a gravity high-mount air intake. The four-valve cylinder head contains straight ports and large 36mm intake valves for exceptional cylinder charging efficiency.
A small cylinder head is produced by a camshaft drive system inspired by a sport bike’s chain and gear arrangement.
Excellent heat transfer and ring sealing are achieved using a SCEM (Suzuki Composite Electrochemical Material) coating on the lightweight aluminum cylinder, leading to exceptional chamber performance.
Additionally, the engine has two balance shafts for a smooth-running engine. Superior throttle response and fuel efficiency are offered by advanced Suzuki fuel injection, which delivers power consistently throughout the rpm range.
Moreover, it boosts the starting engine in all situations. The 2023 KingQuad 750AXi Power Steering SE Plus Utility ATV quickly complies with US emissions regulations.
In California, versions that meet strict emissions standards are eligible for registration with a green sticker.
A large-diameter, thermostatically controlled cooling fan, and high-capacity aluminum radiator provide a stable engine operating temperature.
Transmission Features
With a gate-type shifter located on the fender for high/low range selection, the QuadMatic CVT-type automatic transmission provides simplicity and versatility.
With the throttle off, its advanced engine-braking system reduces freewheeling and helps maintain car control during descents.
A well-chosen CVT spring and weight calibration match the engine’s performance to the chassis’ high towing capacity, allowing for smooth and powerful acceleration from a stop.
Controlled engine braking is made possible by the CVT setting, which increases rider comfort and confidence when riding downhill. A small torque-sensing limited-slip front differential provides significant traction and light steering.
A differential-lock system offers strong four-wheel-drive traction. Handlebar-mounted push-button controls make it easy to select between 2WD, 4WD, and differential lock 4WD.
When removing dirt from the bike, the standard speed limiter can be overridden by pressing the override button on the left handlebar.
Chassis Features
The angular and bold bodywork is coated in a new cast carbon pattern finish or a metallic matte Rocky Grey. High-clearance fenders provide excellent protection for the rider from flying debris.
The body panels were designed especially to facilitate maintenance tasks, for example checking the oil level and servicing the fuel and air filters.
The 2023 KingQuad 750AXi Power Steering SE Plus Utility ATV’s chassis features thick-walled tubes and reinforced brackets at strategic locations to improve ride comfort, make the ATV easier to ride on any terrain and increase towing capacity.
Essential steering characteristics are adjusted for less effort and tight turns in confined spaces. In the “understeer” condition.
This enables the use of more extended and more comfortable handlebars. The state-of-the-art electric power steering system on the 2023 KingQuad 750AXi Power Steering SE Plus Utility ATV dramatically reduces steering effort, vibration, and shock to the rider.
Its capacity is greater than that of the previous model. With 6.7 inches of wheel travel, an all-new independent double A-arm front suspension features gas-charged shock absorbers with five-way spring preload adjustment and a wide diameter. With 7.7 inch wheels.
The travel, fully independent A-arm/I-beam rear suspension features large-diameter, gas-charged shock absorbers with five-way spring preload adjustment. A wide-diameter rear stabilizer bar with responsive bushings aids in control while reducing rider shock—body movement.
For optimal braking performance, twin hydraulic front disc brakes utilize high-lever ratio, fluid lines, and high-friction brake pad materials. The sealed, multi-plate rear brake system’s foot-brake-lever ratio provides excellent rider control.
Utility Features
The direction you steer a 35-watt handlebar-mounted lamp illuminates the 2023 KingQuad 750AXi Power Steering SE Plus Utility ATV. The King Quad’s unique bodywork features dual 35-watt headlights with high and low settings.
An all-new 2023 KingQuad 750AXi Power Steering SE Plus Utility ATV’s stunning, low-draw LED taillight saves energy while increasing low-light visibility. With the King Quad’s large towing capacity (up to 1322 pounds), choosing the type of equipment you want to haul is easy with a receiver-type trailer hitch installation. Winch installation is simplified by wire conduit and winch-ready mounts.
The multi-function instrument panel offers servicing reminders based on mileage or running time and has improved appearance and visibility. The instrument panel has LCD readouts for fuel level, driving range, drive mode, twin trip meter, hour meter, fuel level, and clock.
An eighteen-amp maintenance-free battery is provided by a high-output, three-phase charging system with plenty of power for easy starting and equipment use. As standard, there is a sealed 12V accessory outlet.
The large 17.5 L (4.6 gallon) gasoline tank is low in the center of gravity. It has a ratchet-style filler cap (which opens easily for refilling and prevents overtightening) and a vacuum-operated petcock. The centrally located 4.0-litre storage compartment at the rear of the ATV, which is located forward, offers heavy load capacity.
In the pre-existing 4.0-litre left-side compartment. The front storage section, which holds 2.8 liters and is waterproof, has an easy-to-access screw-on top. Front and rear reinforced steel-tube cargo racks have a wrinkle-resistant paint finish meant to last.
Special Features
Twelve months of limited coverage. The extended warranty period and additional benefits are offered by Suzuki Extended Protection (SEP). Winches, windshields, front and rear bumpers, metal skid pans, rack extensions, utility boxes, and more are among the Suzuki Genuine Accessories. The minimum age of the operator is sixteen years.
2023 KingQuad 750AXi Power Steering SE Plus Utility ATV – Price
The new 2023 KingQuad 750AXi Power Steering SE Plus Utility ATV is available for $11,249 only.
2023 KingQuad 750AXi Power Steering SE Plus Utility ATV – Technical Specifications
Engine
| Engine | 722cc (44.1 cubic in.), liquid-cooled, 4-stroke, 4-valve, DOHC single cylinder |
| Bore x Stroke | 104.0mm x 85.0mm (4.094 inches x 3.346 inches) |
| Compression Ratio | 9.9:1 |
| Fuel System | Suzuki electronic fuel injection |
| Starter | Electric |
| Lubrication | Wet sump |
Drivetrain
| Transmission | Automatic variable ratio (V-belt), featuring high/low-range and reverse |
| Clutch | Dry shoe, automatic, centrifugal type |
| Driven Wheels | 2WD, 4WD and 4WD Differential Lock |
| Final Drive | Shaft drive |
Chassis
| Suspension Front | Independent, coil spring, double wishbone, gas charged, & oil damped including Five-way preload adjustable shock absorbers. |
| Suspension Rear | Independent, coil spring, double wishbone, gas charged & oil damped including 5-way preload adjustable shock absorbers |
| Brakes Front | Disc brakes, twin rotors |
| Brakes Rear | Sealed oil-bathed multi-disc |
| Tires Front | AT25 x 8-12, tubeless type x 2 |
| Tires Rear | AT25 x 10-12, tubeless type x 2 |
| Fuel Tank Capacity | 17.5 Liters (4.6 US gal.) |
| Color | Metallic Matte Rocky Gray or Cast Carbon |
Electrical
| Ignition | Electronic ignition (transistorized) |
| Headlight | 12V 35/35W x 2 fender-mounted, 12V 35W x 1 handlebar-mounted |
| Tail Light | LED |
Dimension
| Overall Length | 2150 mm (84.6 in.) |
| Overall Width | 1215 mm (47.8 in.) |
| Overall Height | 1285 mm (50.6 in.) |
| Wheelbase | 1285 mm (50.6 in.) |
| Ground Clearance | 260 mm (10.2 in.) |
| Seat Height | 920 mm (36.2 in.) |
| Curb Weight | 327 kg (721 lb.), 328 kg (723 lb.) CA model |
Warranty
| Warranty | 12-month limited warranty |
| Extension | More extended coverage periods including some other benefits are available through Suzuki Extended Protection (SEP) |
