Beta never stops honing the frame and suspensions of its bikes. In the quest for even sharper, purer rider response, Betamotor’s engineers have totally revised the internals of the front fork – a ZF component, as on the previous generation – of the 2023 models of the RR family. The 2023 Beta RR 4T 480 Off-Road Bike’s features and specifications are reviewed below.
2023 Beta RR 4T 480 Off-Road Bike – Features and Specs
Engine and Transmission
The new 2023 Beta RR 4T 480 Off-Road Bike has a titanium-valved, single-cylinder four-stroke engine that displaces 477.5 cc and has a compression ratio of 11.9:1. It has a fuel system controlled by Double Overhead Cams/Twin Cam injection and Elldor dual electronic injection. A chain gearbox and a 6-speed gearbox complement the engine’s liquid cooling better than 2021 Beta RR 4T 480.
Chassis, Suspension, Brakes and Wheels
The molybdenum steel frame of the motorbike assures the bike’s stability and longevity thanks to a double cradle split located just above the exhaust port. A hydraulic USD fork provides 295 mm of front suspension travel with a 48 mm shaft.
Monoshock with progressive compound lever offers 290 mm of travel at the rear. The bike has wire-spoked wheels with 90x90x21-inch (F) and 140x80x18-inch (R) tires in the front and rear. The braking system features a 240mm rear disc brake including a single-piston caliper and a 260mm front disc brake with dual-piston calipers.
Physical Measures and Capacities
The molybdenum steel frame of the motorcycle has a twin cradle construction, which increases its stability and longevity. Its 48 mm shaft hydraulic USD fork up front allows for 295 mm of wheel travel, making it a formidable off-road machine.
The mono-shock provides wheel travel of 290 mm with a progressive compound lever at the rear suspension. The front brakes guarantee the stopping power, a single disc with two-piston calipers and a 260 mm diameter, and the rear brakes, a single disc with a 240 mm diameter. The wire-spoked wheels give the bike a more industrial look.
Other Specifications
The starting electric motorcycle is available in three sleek colors—red, white, and black—perfect for fashion-forward eco-rider.
2023 Beta RR 4T 480 Off-Road Bike – Technical Specifications
Engine and transmission
| Displacement | 477.5 ccm (29.14 cubic inches) |
| Engine type | Single-cylinder, four-stroke |
| Engine details | Titanium valves |
| Compression | 11.9:1 |
| Bore x stroke | 100.0 mm x 60.8mm (3.9 inches x 2.4 inches) |
| Valves per cylinder | 4 |
| Fuel system | Injection. Elldor dual electronic injection |
| Fuel control | Double Overhead Cams/Twin Cam (DOHC) |
| Ignition | Kokusan |
| Lubrication system | Two oil pumps |
| Cooling system | Liquid |
| Gearbox | 6-speed |
| Transmission type | Chain (final drive) |
| Clutch | Wet multi-disc |
Chassis, suspension, brakes and wheels
| Frame type | Molybdenum steel with a double cradle split above the exhaust port |
| Front Suspension | Hydraulic USD fork with 48 mm shaft |
| Front-wheel travel | 295 mm (11.6 inches) |
| Rear Suspension | Monoshock with progressive compound lever |
| Rear wheel travel | 290 mm (11.4 inches) |
| Front tire | 90/90-21 |
| Rear tire | 140/80-18 |
| Front brakes | Single disc. 2-piston calipers |
| Diameter | 260 mm (10.2 inches) |
| Rear brakes | Single disc. Single-piston caliper |
| Diameter | 240 mm (9.4 inches) |
| Wheels | Wire spoked |
Physical measures and capacities
| Dry weight | 108.5 kg (239.2 pounds) |
| Seat height | 940 mm (37.0 inches). If adjustable, lowest setting. |
| Overall height | 1270 mm (50.0 inches) |
| Overall length | 2180 mm (85.8 inches) |
| Overall width | 815 mm (32.1 inches) |
| Ground clearance | 320 mm (12.6 inches) |
| Wheelbase | 1490 mm (58.7 inches) |
| Fuel capacity | 9.00 litres (2.38 US gallons) |
| Reserve fuel capacity | 2.30 litres (0.61 US gallons) |
Other specifications
| Color options | Red/white/Black |
| Starter | Electric |
Conclusion
The 2023 Beta RR 4T 480 Off-Road Bike has a robust and highly efficient engine incorporating state-of-the-art fuel injection technology. The strong structure and suspension of the vehicle provide both stability and the capacity to navigate off-road terrain.
The use of wire-spoked wheels, in conjunction with dependable braking systems, contributes to the robust allure of the vehicle. The product has environmentally friendly electronic ignition and a variety of aesthetically pleasing color choices, appealing to those who prioritize performance and style.
