2017 KTM 250 SX – Review & Specification

August 19, 2016

2552

The all-new 2017 KTM 250 SX is considered to be the best bike of KTM Company. The new 2017 KTM 250 SX comes with a powerful engine which has the best power to weight ratios when someone talks about dirt bikes. The dirt bike has amazing sound, charming look, and more importantly lightweight chassis which makes this dirt bike an ideal one. The new 2017 KTM 250 SX dirt bike is indeed for champs who want to win the race, not only win the race but to rewrite the history. The reviews of new 2017 KTM 250 SX are given below.

2017 KTM 250 SX – Specs

Engine

The all-new 2017 KTM 250 SX comes with a powerful engine of 250 ccs. The engine of the bike has a two-stroke technology, which is thought to be the best for the bikes of its class. KTM Company has tested the two-stroke technology on previous models as well and approved this technology best for this new bike. As a result of that, the new dirt bike comes with an outstanding power to weight ratio; a cost is also very low, and the simplicity of the motorcycle is mind blowing.

The new 2017 KTM 250 SX comes with the new shaft arrangement for better centralization of mass, the cylinder of the engine is also new with twin valve which is controlled by power valve, and there is a new counter balance shaft which is specially installed to avoid vibration. The new bike comes with a high five-speed transmission and a hydraulically operated DDS clutch as well. The best feature of the motorcycle is that it has a low maintenance cost, so rider should not be worried about the support of new 2017 KTM 250 SX. The engine of the new dirt bike has an incredible cylinder which is specially designed for this bike. They come with the bore of approximately 66.4 mm, and they got all net ports. They are fitted with an overhauled power valve system. This system of the bike has a sophisticated mechanism for the lateral support exhaust ports which provides a smooth and controllable power. Moreover, the right news is that rider can change the bikes mood within seconds, and all this is possible through the supplied power valve springs. There are limitless settings are available for different tracks and preferences are up for grabs. The new 2017 KTM 250 SX has new water jacket in the cylinder, and the head will take care of excess heat and the reworked lateral cylinder head brackets allows for more heat fixation of the engine to the frame with the help of lightweight head stays. The new 2017 KTM 250 SX comes with an incredible all-new die-cast engine case with features 8 mm higher clutch shaft and the 27 mm larger crankshaft which results from the better mass centralization. The bike also allows the implementation of counter balance shaft so the rider should not be worried about relaxing rider or rideability. Besides, the engine cover will always look as fresh as it was on day one, all this is due to the redesigned engine covers which feature a smart surface structure to reduce the wear caused by the boots of riders. The new 2017 KTM 250 SX comes with a KTM developed DDS clutch (damped diaphragm steel) with a wear-free steel basket. These clutch plates are extremely heat resistant. This intelligent design employs a diaphragm spring instead of the usual coil springs, which makes the clutch action much easier. The diaphragm spring also leaves sufficient space for a damping system to be integrated into the clutch hub. The primary objective of the damping system is to have an excellent traction and durability as well. Moreover, it is fitted with the lighter basket, a reworked inner hub, and a pressure plate which provides a better oil supply and unsurpassed cooling.

The light operation and telepathic control make these clutch, a hydraulic Brembo clutch. The new engine of 2017 KTM 250 SX comes with a lateral counter balance shift to reduce the vibration level; it will help the bike to maintain more comfort and less fatigue. The engine has a five-speed transmission gearbox which has the same gear ratio as 2017 KTM 125 SX and its predecessor, but the engineers of the KTM Company has revised the mechanism to provide a more precise and easier shifting. By keeping safety in mind, an advanced ‘No Dirt’ gear lever design to prevent muck from blocking the joint. Because dirt bike lovers hate mud, when it’s in the wrong place. The exhaust system of the 2017 KTM 250 SX is working incredibly. The KTM engineers tuned the expansion chamber to provide the maximum power. The advanced 3-D production process now ensures the higher precision manufacturing. The crankshaft of the 2017 KTM 250 SX has a 72 mm stroke. The vibration is further minimized with the help of rebalanced, revamped and set-up of a counter balance shaft. The engine of 2017 KTM 250 SX comes with two strokes models which are fitted with new MIKUNI TMX carburetors, replacing the Keihin products. The new 2017 KTM 250 SX comes with the 38 mm flat slide carb lives to provide the smooth and controllable power all the way up to the limiter. The good thing is that it is less sensitive to different altitudes, and temperatures so don’t worry about it and pin it wherever, whenever.

Chassis

The frame of new 2017 KTM 250 SX comes with the lightweight, and the 2017 SX models are slimmest and lightest dirt bike in the market. The design of airbox offers the maximum protection of the air filter against soiling while it guarantees maximum airflow. The large twin air filter is installed in a wooden cage, which at the same time holds the system in place. The design of the air filter is so simple that rider can quickly pop a fresh one in with a face full of mud. Without any help of tools and within few seconds. The new 2017 KTM 250 SX comes with a high-tech lightweight chrome-moly steel frame which has a knack for easy handling, outstanding rideability, excellent stability and precise cornering. This bike has a high torsional rigidity and low longitudinal stiffness. In result of this, it gives a better absorption of the energy which is created from the front and rear suspension, sucking up bumps and jumps. In other words, it offers more comfort and less rider fatigue. The engine head is light in weight and is laterally attached contributes in precise cornering and reduction of vibration level. The KTM engineers were able to reduce the weight of the 2017 KTM 250 SX a kilogram lighter than that of the lightest competitor on the market. The plus point of the 2017 KTM 250 SX bike is that it is very easy to maintain, easy to work and it supplies more space for the tank and some other components as well. The bike also has extra-light subframe made up of solid aluminum profiles, which tiptoes the scales at less than 900 grams. The new 2017 KTM 250 SX bike has a supplicated ‘No Dirt’ footpegs which prevent smudging up the pegs, even when digging in deep ruts. If a rider is looking for the higher riding position, then he should mount the footpegs of the MY2017 EXC models, which are approximately 6 mm greater than the SX versions. The new cast aluminum design of 2017 KTM 250 SX offers a little weight and a perfect flex behavior. The single-component casting process reduces any inconsistencies and some other weak points created by welding.

The handlebars of new 2017 KTM 250 SX is specially designed by KTM engineers. They are made up of high strength aluminum by NEKEN which is fixed in damped rubber mountings and has two different positions as well. From MY2017 to onwards, the lower handlebar clamps are separated, while the upper side has a new bridge type clamp which ensures more torsional stiffness. The replace of the handlebar is also very easy if gets twisted in an accident or a nasty crash. An ODI vulcanized grip is on the right, while on the left side of the handlebar, the comfortable ODI lock-on grip is mounted, which does not require any wire or glue to be fixed. The new 2017 KTM 250 SX comes with a lightweight polyethylene tank with the capacity of about 7 liters of fuel. The cap of filler has an inside thread, which makes a secure and reliable closure. The seat of the dirt bike is designed in such a way so that it meet all the requirement of world’s fastest backsides; the seat is durable as it provides great comfort and less fatigue. The new cover gives a better look, fantastic grip, and excellent feel. The cooling system of the bike has proven to be the best cooling system new 2017 KTM 250 SX. The cooling system routes the coolant from the cylinder head through the frame triangle, directly to the aluminum radiators made by WP. This cooling is extremely efficient due to the flow optimized internal circulation and ventilation of CFD calculated air. Moreover, the radiator guards integrated into the front part of the spoiler provides the protection in case of crashes, which is impressive. The new 2017 KTM 250 SX bike comes with a lightweight, CNC-machined hubs, and the high-end Excel rims, they ensure not only maximum stability but also minimal unsprung weight. The wheels of the dirt bike are shod with the latest Dunlop Geomax MX 3S tires.

Design

The new 2017 KTM 250 SX comes with fantastic Kiska Design which gives quite an impressive look. The primary objective of the KTM engineers was to establish the complete harmony between rider and bike. The new 2017 KTM 250 SX motorcycle comes with perfect ergonomic design and fantastic contact points, maximum freedom of movement, a low seat height which is adjustable and is very comfortable, especially the rear part of the seat gives great comfort. The I-beam structures of the rear and front fenders give the prime example of intelligent design, ensures maximum stability and incredibly low weight, all this is possible due to the thought-out construction and mounting. Moreover, they stay cleaner for the longer period. The new tailor made kit fits a lot for the 2017 KTM 250 SX because it gives a sporty look and champions deserve this bike.

Suspension and brakes

The new 2017 KTM 250 SX motorcycle comes with WP mono shock which has been developed with the entire frame and swingarm design in mind, including the linkage system and the new WP AER 48 front forks. It contains machined and black anodized components and is precious, high-end product as compared to roughcast reservoirs. The all-new setting and the softer spring perfectly match the revised front-end setup and the awesome WP color scheme which lets other to know the excellent taste of rider in suspension. The new 2017 KTM 250 SX bike comes with lightweight WP AER 48 front fork with a 48 mm USD air sprung fork which is developed by WP in close collaboration with the KTM engineers; it is the split fork with separate functions for each leg. It means that damping functions are on the right side, whereas the air spring is on the left side. The left leg contains the two chamber system with a capsule air cartridge to prevent the loss of atmospheric pressure. If the outer seal starts to leak, the internal cartridge pressure will keep the bike in position.

The air spring is very easy to adjust to any weight of rider with the help of single air valve. No other special tools are required. The air pump which comes with the bike will do just fine. The right fork leg integrated the damping cartridge which allows the tailors to all riders damping needs. It can be easily adjusted to any track conditions and any preference of rider with a twist of the dial. For MY2017, the AER 48 also contains the redesigned outer tubes with better characteristics of bending, smoother operation and for less friction. Moreover, they have lost some weight as well, approximately 265 grams. These folks are more comfortable and more sensitive than any other dirt bikes. The new 2017 KTM 250 SX motorcycle comes with a top quality; CNC machined triple clamps which have been a trademark of KTM. It guarantees an accurate handling, they support the flex characteristic and with it the action of the forks. The new 2017 KTM 250 SX comes with the upper triple clamp specifically, features a redesign in conjunction with the new fork tubes. The rubber damped handlebar fixation has also reworked, and the lower handlebar clamps are now entirely separated. The upper side of the new bridge type clamp ensures more torsional stiffness moreover it can easily be replaced just in case it gets twisted due to crash. Moreover, an hour meter is fitted with the upper triple clamp of the bike to let the rider know that it’s time for the service. The new 2017 KTM 250 SX comes with a high-tech Brembo brakes which are combined with the lightweight wave discs made by Galfer. The rear brake for 2017 KTM 250 SX comes with a 10 mm longer brake pedal and the rider gets a new, less aggressive brake pads.
